Product Summary

The SN74ALVC164245DGGR is 16-bit(dual-octal) noninverting bus transceiver. It contains two separate supply rails. The device is designed for asynchronous communication between data buses.

Parametrics

Absolute maximum ratings: (1)input clamp current:-50mA; (2)output clamp current:-50mA; (3)continuous output current:±50mA; (4)continuous current through each VCC or GND:±100mA; (5)package thermal impedance:70℃/W; (6)storage temperature range:-65℃ to 150℃.

Features

Features: (1)member of the Texas instruments widebus family; (2)max tpd of 5.8ns at 3.3V; (3)±24mA output drive at 3.3V; (4)control inputs VIH/VIL levels are referenced to VCCA voltage; (5)latch-up performance exceeds 250mA per JESD 17.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74ALVC164245DGGR
SN74ALVC164245DGGR
Texas Instruments
Translation - Voltage Levels Tri-State 16-Bit
Data Sheet
0-1: $0.84
1-25: $0.66
25-100: $0.60
100-250: $0.56
