Product Summary

The MCP2551-I/SN is a high-speed CAN, fault-tolerant device that serves as the interface between a CAN protocol controller and the physical bus. The device provides differential transmit and receive capability for the CAN protocol controller, and is fully compatible with the ISO-11898 standard, including 24V requirements.

Parametrics

Absolute maximum ratings: (1)VDD:7.0V; (2)DC Voltage at TXD, RXD, VREF and VS:-0.3V to VDD + 0.3V; (3)DC Voltage at CANH, CANL : -42V to +42V; (4)Transient Voltage on Pins 6 and 7:-250V to +250V; (5)Storage temperature:-55℃ to +150℃; (6)Operating ambient temperature:-40℃ to +125℃; (7)Virtual Junction Temperature, TVJ:-40℃ to +150℃; (8)Soldering temperature of leads (10 seconds):+300℃; (9)ESD protection on CANH and CANL pins:6 kV; (10)ESD protection on all other pins:4 kV.

Features

Features: (1)Supports 1 Mb/s operation; (2)Implements ISO-11898 standard physical layer requirements; (3)Suitable for 12V and 24V systems; (4)Externally-controlled slope for reduced RFI emissions; (5)Detection of ground fault (permanent Dominant) on TXD input; (6)Power-on Reset and voltage brown-out protection; (7)An unpowered node or brown-out event will not disturb the CAN bus; (8)Low current standby operation; (9)Protection against damage due to short-circuit conditions(positive or negative battery voltage); (10)Protection against high-voltage transients; (11)Automatic thermal shutdown protection; (12)Up to 112 nodes can be connected; (13)High-noise immunity due to differential bus implementation.
