Product Summary

The BA50BC0FP-E2 is a low-saturation regulator with an output current of 1.0 A and an output voltage accuracy of 2%. A broad output voltage range is offered, from 1.5V to 10V, and built-in overcurrent protection and thermal shutdown (TSD) circuits prevent damage due to short-circuiting and overloading, respectively.

Parametrics

BA50BC0FP-E2 absolute maximum ratings: (1)Power supply voltage, VCC: 18 V; (2)Power dissipation: TO252-3, Pd: 1200 mW; TO252-5, Pd:1300mW; TO220FP-3, Pd: 2000mW; TO220FP-5, Pd: 2000mW; TO220FP-5 (V5), Pd: 2000mW; TO220CP-V5, Pd: 2000mW; (3)Operating temperature range, Topr: -40 to +105 ℃; (4)Ambient storage temperature, Tstg: -55 to +150 ℃; (5)Maximum junction temperature, Tjmax: 150 ℃.

Features

BA50BC0FP-E2 features: (1)Output current: 1 A (min.); (2)Output voltage accuracy: 2%; Broad output range available: 1.5 V -10 V; (3)Low saturation-voltage type with PNP output; (4)Built-in overcurrent protection circuit; (5)Built-in thermal shutdown circuit; (6)Integrated shutdown switch ; (7)Operating temperature range: -40℃ to +105℃.

Diagrams

BA50BC0FP-E2 Block Diagrams / Standard Example Application Circuits

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BA50BC0FP-E2
BA50BC0FP-E2
ROHM Semiconductor
Low Dropout (LDO) Regulators IC LDO 1A 5V
Data Sheet
0-1: $0.66
1-25: $0.59
25-100: $0.50
100-500: $0.35
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BA500120500003BK
BA500120500003BK

BATTERY CHG UNIV 12VDC @ 500MA
Data Sheet
0-1: $16.72
1-10: $13.59
10-25: $13.33
25-50: $13.07
50-100: $12.80
100-250: $12.54
BA500120500003NK
BA500120500003NK
Ault / SL Power
Battery Chargers 12V .5A 7.35W
Data Sheet
0-1: $15.90
1-10: $15.37
10-25: $14.40
25-50: $13.62
BA50BC0FP-E2
BA50BC0FP-E2
ROHM Semiconductor
Low Dropout (LDO) Regulators IC LDO 1A 5V
Data Sheet
0-1: $0.66
1-25: $0.59
25-100: $0.50
100-500: $0.35
BA50BC0T
BA50BC0T
ROHM Semiconductor
Low Dropout (LDO) Regulators IC LDO 1A 5V
Data Sheet
0-1: $0.83
1-25: $0.70
25-100: $0.56
100-500: $0.39
BA50BC0WFP-E2
BA50BC0WFP-E2
ROHM Semiconductor
Low Dropout (LDO) Regulators REG 1A 5V
Data Sheet
0-2000: $0.26
BA50BC0WT
BA50BC0WT
ROHM Semiconductor
Low Dropout (LDO) Regulators REG 1A 5V
Data Sheet
0-1: $1.00
1-25: $0.83
25-100: $0.67
100-500: $0.47
